Gamme |
Uniarch |
Capteur d'image |
1/2.8” Progressive Scan CMOS |
Résolution maximale |
2 Megapixel (1920x1080) |
Taux Main Stream |
1080P (1920*1080@25fps; 720P (1280*720)@25fps |
Taux Extra Stream |
D1 (720*576)@25fps; 640*360@25fps; 2CIF(704*288)@25fps; CIF(352*288)@25fps |
DORI |
43.4 (D), 17.4 (O), 8.7 (R), 4.3 (I) |
Champ de vision |
106.7° (H), 57.1° (V), 115.7° (D) |
Compression |
Ultra265/H.265/H.264 |
Objectif |
2.8 mm |
Illumination minimale |
0.02 Lux (Couleur) |
Portée infrarouge |
30 m |
Améliorations d'image |
DWDR, AGC, 2D/3D-NR, Motion detection, ROI, Privacy Mask, Smart IR |
Jour / Nuit |
Filtre mécanique ICR |
Stockage interne |
Non disponible |
Alarmes |
Non disponible |
Audio |
Non disponible |
Interface réseau |
Ethernet 10/100 BaseT |
Accès distant |
Moteur de recherche Web, Logiciel CMS (EZStation), Smartphone (EZView/EZLive) |
Interopérabilité |
ONVIF |
Alimentation |
DC 12 V / 3.5 W, PoE IEEE802.3af |
Temp. fonctionnement |
-30º C ~ 60º C |
Degré de protection |
Étanche IP67 |
Dimensions |
118 (H) x 97 (L) mm |
Poids |
250 g |
