| Gamme |
Uniarch |
| Capteur d'image |
1/2.8” Progressive Scan CMOS |
| Résolution maximale |
2 Megapixel (1920x1080) |
| Taux Main Stream |
1080P (1920*1080)@25fps; 720P (1280*720)@25fps |
| Taux Extra Stream |
D1 (720*576)@ 25fps; 640*360@25fps; 2CIF(704*288)@25fps; CIF(352*288)@25fps |
| DORI |
45 m (D), 18 m (O), 9 m (R), 4.5 m (I) |
| Champ de vision |
101.1° (H), 55° (V), 111° (D) |
| Compression |
Ultra265/H.265/H.264 |
| Objectif |
2.8 mm |
| Illumination minimale |
0.02 Lux (Couleur) |
| Portée infrarouge |
30 m |
| Améliorations d'image |
DWDR, AGC, 2D/3D-NR, Motion detection, ROI, Privacy Mask, Smart IR |
| Jour / Nuit |
Filtre mécanique ICR |
| Stockage interne |
Non disponible |
| Alarmes |
Non disponible |
| Audio |
Non disponible |
| Interface réseau |
Ethernet 10/100 BaseT |
| Accès distant |
Moteur de recherche Web, Logiciel CMS (EZStation), Smartphone (EZView/EZLive) |
| Interopérabilité |
ONVIF |
| Alimentation |
DC 12 V / 3.2 W, PoE IEEE802.3af |
| Temp. fonctionnement |
-30º C ~ 60º C |
| Degré de protection |
Étanche IP67 |
| Dimensions |
160 (H) x 62 (L) x 65 (Pr) mm |
| Poids |
210 g |
